Piezoresistive Siab Hloov
● Puv cov digital Circuit Court, ua haujlwm zoo.
● Muaj kev ua haujlwm siab, ua kom muaj nuj nqis.
Dav ntsuas qhov ntsuas qhov dav: -1 ... 0 ~ 0.1 ... 1000bar.
Muaj zog tiv thaiv jamming.
Piezoresistive Siab Hloov
Kev piav qhia
UPB13 piezoresistive siab transmitter siv UPX19 piezo-resistive silicon sensor raws li hnov lub ntsiab lus. Nws txais yuav DSP tshiab tshaj tawm cov teeb liab digital algorithm Circuit Court, uas yog qhov tshwj xeeb nrog kev tiv thaiv siab-tiv thaiv thiab cuam tshuam rau kev ua tau zoo, thiab qhov zoo tsis-linearity kho rau cov sensors. Qhov no ua rau piezoresistive siab transmitter muaj zoo linearity caracteristicas. UPB13 piezoresistive siab transmitter yog tsim los nrog tag nrho cov hlau tsis muaj zog, thiab nws cov installation tau yooj yim heev. Nws yog cov khoom lag luam raug nqi zoo.
Nta
● Puv cov digital Circuit Court, ua haujlwm zoo
● Muaj kev ua haujlwm siab, ua kom muaj nuj nqis
Dav ntsuas qhov ntsuas qhov dav: -1 ... 0 ~ 0.1 ... 1000bar
Muaj zog tiv thaiv jamming
Cov Lus Qhia Tshwj Xeeb
| siab nruab nrab | roj lossis ua kua tau haum nrog hlaus hlau |
| siab yog hom twg | -1 ... 0 ~ 0.1 ... 1000bar |
| sib tshooj siab | 150% FS |
| tso zis teeb liab | 4 ~ 20mA, 0 ~ 5V, 0 ~ 10V, 1 ~ 5V |
| raug | 0.25% FS, 0.5% FS |
| thauj kuj | R L = (U-9V) /0.02A (4 ~ 20mA cov zis tam sim no) U-voj voltage (V) |
| muab voltage | 9 ~ 36VDC |
| compensated kub ntau yam | -10 ~ 70 ℃ |
| kev khiav hauj lwm kub ntau | -30 ~ + 100 ℃ |
| ntsuas qhov ntsuas kub ntau | -40 ~ + 125 ℃ |
| cov txheej txheem kev sib txuas | G1 / 4 lossis lwm tus |
| hluav taws xob txuas | hirschmann txuas lossis lwm tus |
| cov khoom ntawm wetted | 304 stainless hlau |
| cov khoom ntawm siab ntsws | 316L stainless hlau |
| cov khoom ntawm vaj tsev | 304 stainless hlau |
UPB13 piezoresistive siab transmitter dav siv rau kev ntsuas siab thiab tswj cov roj av, tshuaj lom neeg-kev lag luam, metallurgy, chaw nres tsheb fais fab thiab hydrology, thiab lwm yam.
