Kev Sib Tw Siab Kev Hloov Hluav Taws Xob

▲ Muaj kev ua haujlwm siab, ua kom muaj nuj nqis.
▲ Puv cov digital Circuit Court, ua haujlwm zoo.
Muaj zog tiv thaiv jamming.
Dav ntsuas qhov ntsuas qhov dav: -1 ... 0 ~ 0.1 ... 1000bar.

Xa kev nug

sis tw siab transmitter

Kev Sib Tw Siab Kev Hloov Hluav Taws Xob

Kev piav qhia

UPB13 kev sib tw siab transmitter siv UPX19 piezo-resistive silicon sensor raws li hnov lub ntsiab lus. Nws txais yuav qhov tseeb DSP digital teeb liab txias algorithm Circuit Court, lub Circuit Court muaj qhov siab nrog tiv thaiv kev cuam tshuam & kev cuam tshuam los tiv thaiv kev ua tau zoo, kuj nrog qhov zoo tsis-linearity kho rau cov sensors, qhov no ua rau UPB13 kev sib tw siab transmitter muaj cov kab txaij zoo tshaj plaws.

UPB13 kev sib tw siab transmitter yog tsim los nrog tag nrho cov hlau tsis muaj zog, thiab nws cov installation tau yooj yim heev.

Nta

▲ Muaj kev ua haujlwm siab, ua kom muaj nuj nqis

▲ Puv cov digital Circuit Court, ua haujlwm zoo

Muaj zog tiv thaiv jamming

Dav ntsuas qhov ntsuas qhov dav: -1 ... 0 ~ 0.1 ... 1000bar

Cov Lus Qhia Tshwj Xeeb

siab yog hom twg	-1 ... 0 ~ 0.1 ... 1000bar
sib tshooj siab	150% FS
tso zis teeb liab	4 ~ 20mA, 0 ~ 5V, 0 ~ 10V, 1 ~ 5V
raug	0.25% FS (qauv), 0.5% FS
thauj kuj	R _L = (U-9V) /0.02A (4 ~ 20mA cov zis tam sim no) U-voj voltage (V)
muab voltage	9 ~ 36VDC
compensated kub ntau yam	-10 ~ 70 ℃
kev khiav hauj lwm kub ntau	-30 ~ + 100 ℃
ntsuas qhov ntsuas kub ntau	-40 ~ + 125 ℃
qhov ntsuas kub coefficient ntawm xoom	0.2% FS / 10 ℃
qhov ntsuas kub coefficient ntawm kev ncua	0.2% FS / 10 ℃
cov txheej txheem kev sib txuas	G1 / 2 lossis lwm tus
hluav taws xob txuas	hirschmann lossis PG7 txuas
cov khoom ntawm siab ntsws	316L stainless hlau
cov khoom ntawm vaj tsev	304 stainless hlau

Thov

UPB13 kev sib tw siab transmitter dav siv rau kev ntsuas siab thiab tswj cov roj av, tshuaj lom neeg-kev lag luam, metallurgy, chaw nres tsheb fais fab thiab ntsuas dej, thiab lwm yam.
